Item Component Spare part number
(2) Top cover (includes keyboard and TouchPad) 854457-001
(3) Hard drive (see Hard drive on page 23) 683839-855
(4) Optical drive dummy (see Optical drive dummy on page 22) 854470-001
(5) Battery (see Battery on page 22) 854472-001
(6) Memory (see Memory on page 25) 691799-855
(7) WLAN module (see WLAN module on page 28) 792505-855
(8) RTC battery 855483-001
(9) Webcam (see Webcam on page 45) 854509-001
(10) Fan (see Heat sink and fan on page 30) 854468-001
Heat sink (see Heat sink and fan on page 30) 854469-001
(11) Speaker (see Speakers on page 32) 854475-001
(12) System board (see System board on page 36) 854479-001
(13) Base enclosure 854473-001
12 Chapter 3 Illustrated parts catalog
