HP Notebook 14

2. Remove 4 screws from the right hinge and 3 screws from the left hinge (1), and then remove the display
assembly (2).
3. Slide a nylon ake tool (1) around the outer edge of the bezel to release the bezel from the screen (2).
42 Chapter 5 Removal and replacement procedures for authorized service provider parts
