HP OMEN 34c User Manual

22
Function test
After repair, be sure to confirm that all functions are working.
Function test
After repair, be sure to confirm that all functions are working.
Table 4-1: Function test
Te
st item
Operating description
Tool used
HDMI test
Confirm whether image displays and sound plays correctly on
the monitor.
Computer or DVD player
DP test
Confirm whether image displays and sound plays correctly on
the monitor.
Computer or DVD player
Audio test
Change volume and balance to confirm whether volume is
smooth and loud enough.
Speaker
Table 4-1: Function test
Test item
Operating description
Tool used
HDMI test
Confirm whether image displays and sound plays
correctly on the monitor.
Computer or DVD
player
DP test
Confirm whether image displays and sound plays
correctly on the monitor.
Computer or DVD
player
Audio test
Change volume and balance to confirm whether
volume is smooth and loud enough.
Speaker

HP OMEN 34c Specifications

General

Haze rate	40 %
Panel type	VA
Color gamut	90 %
Pixel pitch	0.23 x 0.23 mm
Pixel density	110 ppi
Backlight type	Edge LED
Display diagonal	34 \
Surface hardness	3H
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LED
Native aspect ratio	21:9
Vertical scan range	60 - 165 Hz
Horizontal scan range	30 - 255 kHz
Screen curvature rating	1500R
Viewable size, vertical	333.7 mm
sRGB coverage (typical)	99 %
Display number of colors	16.7 million colors
Viewable size, horizontal	797.2 mm
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3440 x 1440
High Dynamic Range (HDR) supported	Yes
DisplayPort version	1.4
Headphone connectivity	3.5 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	90 W
Power consumption (standby)	0.5 W
Power consumption (typical)	76 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	227 mm
Package width	911 mm
Package height	465 mm
Package weight	15390 g
Tilt angle range	-5 - 20 °
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
Cables included	AC
Certification	BIS; BSMI; CB; CCC; CE; CEL; CSA; EAC; FCC; ISO 9241-307; KC/KCC; Microsoft WHQL Certification; NOM; PSB; TUV Bauart; TUV LBL; VCCI; WEEE; ISC; California Energy Commission (CEC); WW application; ICE; Ukraine certificates; TÜV Flicker free certified; UAE safety; UAE RoHS; South Africa safety
Product color	Black
Market positioning	Gaming
AMD FreeSync type	FreeSync Premium
RMS rated power	6 W

Weight and Dimensions

Depth (with stand)	243.3 mm
Width (with stand)	807.9 mm
Height (with stand)	584 mm
Weight (with stand)	10590 g
Depth (without stand)	108.4 mm
Height (without stand)	366.7 mm
