6
Rear components
To identify the components on the rear of the monitor, use this illustration and table.
Rear components and their descriptions
Component
Description
(1)
Power button
Turns the monitor on or off.
(2)
OSD control
Adjusts settings in the OSD menu.
(3)
Power connector
Connects the power cord to the monitor.
(4)
HDMI ports (2)
Connect the HDMI cable to a source device such as a computer or game console.
(5)
DisplayPort connector
Connects the DisplayPort cable to a source device such as a computer or game console.
(6)
Audio-out (headphone) jack

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP OMEN 34c and is the answer not in the manual?

HP OMEN 34c Specifications

General IconGeneral
Haze rate40 %
Panel typeVA
Color gamut90 %
Pixel pitch0.23 x 0.23 mm
Pixel density110 ppi
Backlight typeEdge LED
Display diagonal34 \
Surface hardness3H
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display technologyLED
Native aspect ratio21:9
Vertical scan range60 - 165 Hz
Horizontal scan range30 - 255 kHz
Screen curvature rating1500R
Viewable size, vertical333.7 mm
sRGB coverage (typical)99 %
Display number of colors16.7 million colors
Viewable size, horizontal797.2 mm
Display brightness (typical)400 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3440 x 1440
High Dynamic Range (HDR) supportedYes
DisplayPort version1.4
Headphone connectivity3.5 mm
AC input voltage100 - 240 V
Power supply typeInternal
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)90 W
Power consumption (standby)0.5 W
Power consumption (typical)76 W
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)20 - 80 %
Package depth227 mm
Package width911 mm
Package height465 mm
Package weight15390 g
Tilt angle range-5 - 20 °
Height adjustment100 mm
Panel mounting interface100 x 100 mm
Cables includedAC
CertificationBIS; BSMI; CB; CCC; CE; CEL; CSA; EAC; FCC; ISO 9241-307; KC/KCC; Microsoft WHQL Certification; NOM; PSB; TUV Bauart; TUV LBL; VCCI; WEEE; ISC; California Energy Commission (CEC); WW application; ICE; Ukraine certificates; TÜV Flicker free certified; UAE safety; UAE RoHS; South Africa safety
Product colorBlack
Market positioningGaming
AMD FreeSync typeFreeSync Premium
RMS rated power6 W
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)243.3 mm
Width (with stand)807.9 mm
Height (with stand)584 mm
Weight (with stand)10590 g
Depth (without stand)108.4 mm
Height (without stand)366.7 mm
