Processor
Description Spare part number
Intel Core2 Duo processors (include replacement thermal material)
E8500, 6-MB cache, 3.16 GHz 466170-001
E8400, 6-MB cache, 3.00 GHz 509554-001
E7600, 3-MB cache, 3.06 GHz 573954-001
E7500, 3-MB cache, 2.93 GHz 586745-001
Intel Pentium processors (include replacement thermal material)
E6800, 2-MB cache, 3.33 GHz 631758-001
E6700, 2-MB cache, 3.20 GHz 617840-001
E5800, 2-MB cache, 3.20 GHz 646376-001
E5700, 2-MB cache, 3.00 GHz 631759-001
E5500, 2-MB cache, 2.80 GHz 613035-001
Intel Celeron processor (include replacement thermal material)
E3500, 1-MB cache, 2.70 GHz 633219-001
To remove the processor:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 27).
2. Position the computer with the rear facing you.
3. Remove the small rear cover (see
Small Rear Cover on page 28).
4. Remove the stand (see
Stand on page 29).
5. Remove the right rear cover (see
Right Rear Cover on page 35).
6. Remove the heat sink (see
Heat Sink (Thermal Module) on page 38).
7. Rotate the locking lever to its full open position (1).
8. Lift the processor cover (2).
40 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
