Display Panel
Description Spare part number
Display, 20-inch, non-glare 646794-001
The display panel is secured with 4 screws.
To remove the display panel:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 27).
2. Remove the small rear cover (see
Small Rear Cover on page 28).
3. Remove the stand (see
Stand on page 29).
4. Remove the right rear cover (see
Right Rear Cover on page 35).
5. Remove the heat sink (see
Heat Sink (Thermal Module) on page 38).
6. Remove the rear cover (see
Rear Cover on page 46).
7. Remove the system board shield (see
System Board Shield on page 51).
8. Remove the system board (see
System Board on page 56).
9. Remove the stand bracket (see
Stand Bracket on page 58).
10. Remove the drive connectors (see
Drive Connectors on page 59).
11. Remove the front bezel (see
Front Bezel on page 60).
Display Panel 63
