where cabinet x and cabinet y are cabinets or equipment resting partially on the same floor panel.
Weight and Pressure Loads
Depending on the configuration, a storage system can weigh up to 2,000 lb (907 kg). Table 11
(page 20) provides maximum weights and pressure loads per leveling foot for storage system
cabinets. Use these values to approximate the structural support required by a storage system
cabinet.
Table 11 Maximum Weights and Pressure Loads
Maximum LoadPer Leveling
Foot
Maximum Weight Per
Leveling Foot
Maximum WeightCabinet Size
161 lb/sq in.(73 kg/sq cm)500 lb(226.8 kg)2,000 lb(907.2 kg)2M (40U)
NOTE: Table 4.2 uses nominal numbers to simplify calculations.
Tile Cutout Specifications
Figure 7 (page 21) shows the recommended tile cutout specifications for storage system cabinets.
20 Structural/Environmental Considerations
