Item Component Spare part number
(1) Display panel (see Display assembly on page 58) not spared
(2) Top cover with TouchPad and keyboard (see TouchPad on page 49 for a detailed list of country codes)
Natural silver 858971-xx1
Shadow black L03595-xx1
(3) TouchPad (included with top cover)
For use in model numbers: 15-bc000~15-bc099 and 15-bc200~15-bc299 860363-001
For use in model numbers: 15-bc300~15-bc399 L06001-001
(4) Speaker Kit 858976-001
(5) USB board cable 856729-001
(6) RTC battery 741976-001
(7) Power connector (includes cable) 858021-001
(8) Power button board 858974-001
Power button board cable (not illustrated) 858966-001
(9) Solid-state drive (M.2)
128 GB, SATA-3. TLC 759848-032
128 GB, SATA-3, Value 827560-017
256 GB, PCIe 3x4 SS, TLC 847109-005
512 GB, PCIe3x4 SS, TLC 847110-002
(10) System board (see System board on page 53)
(11) Memory module
DDR4, 2133 MHz
●
4 GB 820569-005
●
8 GB 820570-005
●
2 GB 851379-005
DDR4, 2400 MHz
●
4 GB 862397-855
●
8 GB 862398-855
●
2 GB 864271-855
(12) WLAN module, Intel Dual Band wireless-AC 7265 802.11 AC, 2x2, WiFi + Bluetooth 4.2
Combo Adapter (non-vPro)
793840-005
(13) PCH heat sink 725625-001
(14) Heat sink
For use in models with GeForce 950M/960M/965M graphics 856668-001
For use in models with GeForce GTX1050M graphics 920563-001
22 Chapter 3 Illustrated parts catalog
