TouchPad
Description Spare part number
TouchPad board for use in model numbers: 15-bc000~15-bc099 and 15-bc200~15-bc299 860363-001
TouchPad board for use in model numbers: 15-bc300~15-bc399 L06001-001
TouchPad cable 858967-001
Top cover with TouchPad and backlit keyboard in natural silver nish 858971-001
Top cover with TouchPad and backlit keyboard in shadow black nish L03595-001
For use in country
or region
Spare part
number
For use in country
or region
Spare part
number
For use in country
or region
Spare part
number
Belgium -A41 India -002 Slovenia -BA1
Bulgaria -261 Israel -BB1 South Korea -AD1
Canada -DB1 Italy -061 Spain -071
Czech Republic
and Slovakia
-FL1 The Netherlands -B31 Switzerland -BG1
Denmark, Norway,
Finland, and Sweden
-DH1 Northern Africa -FP1 Taiwan -AB1
France -051 Norway -091 Thailand -281
Germany -041 Portugal -131 Turkey -141
Greece -151 Romania -271 United Kingdom -031
Hungary -211 Russia -251 United States -001
Iceland -DD1 Saudi Arabia -171
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the TouchPad, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the base enclosure (see Base enclosure on page 32).
5. Disconnect the cable from the battery.
Remove the TouchPad:
1. Remove the 3 Phillips M 2.0x2.0 screws that secure the TouchPad bracket (1), and then lift the TouchPad
bracket (2) to remove it.
Component replacement procedures 49
