8. To remove the raw panel, remove the six Phillips screws (1) and any adhesive that secures the
display panel to the back cover and lift the display panel (2) carefully.
NOTE: Depending on your specific model, some computers only have four display panel
screws.
9. Remove the display panel side bracket (select models only) by removing the four Phillips screws
(1) and releasing the side bracket (2).
NOTE: If your computer model does not have side brackets, skip to the next step.
Component replacement procedures 93
