Item Component Spare part number
(1) 14.0-in, high definition (HD), light-emitting diode (LED), BrightView SVA display assembly
(includes microphone and wireless antenna transceivers and cables):
In espresso black finish 650463-001
In Pacific blue finish 650465-001
In ruby red finish 650467-001
NOTE: For more display assembly spare part information, see
Display assembly subcomponents on page 24.
(2) Keyboard (includes keyboard cable):
Black keyboard for use with all computer models in Latin America 650470-161
Black keyboard for use only with computer models equipped with an Intel processor:
For use in Brazil 650470-201
For use in Canada 650470-121
For use in the United States 650470-001
Silver keyboard for use with all computer models in Latin America 654484-161
Silver keyboard for use only with computer models equipped with an Intel processor:
For use in Brazil 654484-201
For use in French Canada 654484-121
For use in the United States 654484-001
Silver keyboard with backlight for use only with computer models equipped with an Intel processor (includes
backlight cable):
For use in Canada 650471-121
For use in the United States 650471-001
(3) Top cover (includes TouchPad and TouchPad cable)
In espresso black finish 650487-001
In Pacific blue finish 650490-001
In ruby red finish 650489-001
(4) Power button board (includes cable) 650475-001
(5) TouchPad LED board (includes cable) 650477-001
(6) TouchPad button board (includes bracket and cable) 650476-001
(7) Optical drive connector cable (includes bracket) 650456-001
(8) Audio/USB board:
For use only on computer models equipped with a graphics subsystem with
discrete memory
660308-001
For use only on computer models equipped with a graphics subsystem with
UMA memory
650474-001
20 Chapter 3 Illustrated parts catalog
