Item Component Spare part number

NOTE: The audio/USB board spare part kit does not include the audio/USB board cable. The audio/USB board

cable is included in the Cable Kit, spare part number 652696-001.

Plastics Kit, includes: 650478-001

(9a) Hard drive compartment cover (includes one captive screw, secured by a C-clip)

(9b) Memory module/wireless module compartment cover (includes one captive screw, secured by a C-clip)

NOTE: See

Plastics Kit on page 28 for more Plastics Kit spare part information.

(10) Power connector cable (includes bracket) 650457-001

(11) System board (includes replacement thermal material):

For use only with computer models equipped with an AMD processor and a graphics

subsystem with discrete video memory (includes 1-GB of graphics subsystem memory)

653427-001

For use only with computer models equipped with an AMD processor and a graphics

subsystem with UMA video memory

653428-001

For use only with computer models equipped with an Intel processor and a graphics

subsystem with discrete video memory (includes 1-GB of graphics subsystem memory)

650486-001

For use only with computer models equipped with an Intel processor and a graphics

subsystem with UMA video memory

650485-001

Thermal Material Kit (includes replacement thermal paste and pads) 651046-001

(12) Processor (includes replacement thermal material):

AMD Sabine A8-3530MX 2.6-GHz processor (1.9-GHz FSB, 4.0-MB L2 cache,

Quad Core, 45 W)

653364-001

AMD Sabine A8-3510MX 2.5-GHz processor (1.5-GHz FSB, 4.0-MB L2 cache,

Quad Core, 45 W)

653358-001

AMD Sabine A8-3500M 2.4-GHz processor (1.5-GHz FSB, 4.0-MB L2 cache,

Quad Core, 35 W)

653350-001

AMD Sabine A6-3410MX 2.3-GHz processor (1.6-GHz FSB, 4.0-MB L2 cache,

Quad Core, 45 W)

653357-001

AMD Sabine A6-3400M 2.3-GHz processor (1.4-GHz FSB, 4.0-MB L2 cache,

Quad Core, 35 W)

653349-001

AMD Sabine A4-3310MX 2.5-GHz processor (2.1-GHz FSB, 2.0-MB L2 cache,

Dual Core, 45 W)

653356-001

AMD Sabine A4-3300M 2.5-GHz processor (1.9-GHz FSB, 2.0-MB L2 cache,

Dual Core, 35 W)

653348-001

Intel Core i5-2540M 2.60-GHz (SC turbo up to 3.30-GHz) processor (3.0-MB

L3 cache, Dual Core, 35 W)

631253-001

Intel Core i5-2520M 2.50-GHz (SC turbo up to 3.20-GHz) processor (3.0-MB

L3 cache, Dual Core, 35 W)

631255-001

Intel Core i5-2430M 2.40-GHz (SC turbo up to 3.00-GHz) processor (3.0-

MB L3 cache, dual core, 35 W)

653341-001

Computer major components
