Spare part number Description

634862-001 320-GB, 7200-rpm, 7.0-mm, SATA hard drive (does not include hard drive connector cable, hard

drive bracket, or screws)

634925-001 500-GB, 7200-rpm, 7.0-mm, SATA hard drive (does not include hard drive connector cable, hard

drive bracket, or screws)

636631-001 9-cell, 100-Whr, 3.00-Ah Li-ion battery

638037-001 Intel Core i3-2310M 2.10-GHz processor (3.0-MB L3 cache, Dual Core, 35 W; includes

replacement thermal material)

638039-001 Intel Core i5-2410M 2.30-GHz (SC turbo up to 2.90-GHz) processor (3.0-MB L3 cache,

Dual Core, 35 W; includes replacement thermal material)

638974-001 1-TB, 5400-rpm, 12.7-mm, SATA hard drive (does not include hard drive connector cable, hard

drive bracket, or screws)

639738-001 1-GB memory module (PC3, 10600, 1333-MHz)

640926-001 Realtek 8188GN 802.11b/g/n 1×1 WiFi Adapter

650444-001 WLAN Antenna Kit (includes left and right WLAN antenna cables and transceivers)

650445-001 WWAN Antenna Kit (includes left and right WWAN antenna cables and transceivers)

650446-001 Display enclosure in espresso black finish

650448-001 Display enclosure in ruby red finish

650449-001 Display enclosure in Pacific blue finish

650453-001 Base enclosure (includes battery release latch, heat sink, replacement thermal material, and 4

rubber feet)

650454-001 Display bezel

650455-001 Display Cable Kit (includes display panel cable and webcam/microphone module cable)

650456-001 Optical drive connector cable

650457-001 Power connector cable

650458-001 Heat sink for use only with computer models equipped with a graphics subsystem with UMA video

memory (includes replacement thermal material)

650459-001 Heat sink for use only with computer models equipped with an Intel processor and a graphics

subsystem with discrete video memory (includes replacement thermal material)

650460-001 Fan for use only with computer models equipped with a graphics subsystem with

UMA video memory

650461-001 Display Hinge Kit (includes left and right display hinges and brackets)

650462-001 Display hinge covers

650463-001 14.0-in, HD, LED, BrightView SVA display assembly in espresso black finish (includes microphone

and wireless antenna transceivers and cables)

650465-001 14.0-in, HD, LED, BrightView SVA display assembly in Pacific blue finish (includes microphone

and wireless antenna transceivers and cables)

30 Chapter 3 Illustrated parts catalog
