Spare part number Description

650467-001 14.0-in, HD, LED, BrightView SVA display assembly in ruby red finish (includes microphone and

wireless antenna transceivers and cables)

650470-001 Black keyboard for use in North America (for use only with computer models equipped with an

Intel processor; includes keyboard cable)

650470-121 Black keyboard for use in Canada (for use only with computer models equipped with an

Intel processor; includes keyboard cable)

650470-161 Black keyboard for use in Latin America (includes keyboard cable)

650470-201 Black keyboard for use in Brazil (for use only with computer models equipped with an

Intel processor; includes keyboard cable)

650471-001 Silver keyboard with backlight for use in North America (for use only with computer models

equipped with an Intel processor; includes keyboard cable and backlight cable)

650471-121 Silver keyboard with backlight for use in French Canada (for use only with computer models

equipped with an Intel processor; includes keyboard cable and backlight cable)

650472-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive

650473-001 Blu-ray ROM DVD±R/RW Super Multi Double-Layer Drive

650474-001 Audio/USB board for use on computer models equipped with a graphics subsystem with

UMA memory

NOTE: The audio/USB board spare part kit does not include the audio/USB board cable. The

audio/USB board cable is included in the Cable Kit, spare part number 652696-001.

650475-001 Power button board (includes cable)

650476-001 TouchPad button board (includes bracket and cable)

650477-001 TouchPad LED board (includes bracket and cable)

650478-001 Plastics Kit (includes hard drive compartment cover and memory module/wireless module

compartment cover)

NOTE: See

Plastics Kit on page 28 for more Plastics Kit spare part information.

650479-001 14.0-in, HD, LED, BrightView SVA display panel

650480-001 Rubber Feet Kit (includes four rubber feet)

650481-001 Display Rubber Kit (includes 2 rubber screw covers)

650482-001 Screw Kit

650483-001 Display Screw Kit

650484-001 Speaker (includes cable)

650485-001 System board for use only with computer models equipped with an Intel processor and a graphics

subsystem with UMA video memory (includes replacement thermal material)

650486-001 System board for use only with computer models equipped with an Intel processor and a graphics

subsystem with discrete video memory (includes replacement thermal material)

650487-001 Top cover in espresso black finish (includes TouchPad and TouchPad cable)

650489-001 Top cover in ruby red finish (includes TouchPad and TouchPad cable)

Sequential part number listing
