Spare part number Description

650490-001 Top cover in Pacific blue finish (includes TouchPad and TouchPad cable)

650494-001 Webcam/microphone module

651046-001 Thermal Material Kit for use only with computer models equipped with a graphics subsystem with

UMA video memory (includes replacement thermal paste and pads)

652696-001 Cable Kit (includes the hard drive connector cable and the audio/USB board cable)

NOTE: See

Cable Kit on page 25 for more Cable Kit spare part information.

653337-001 Intel Pentium B940 2.00-GHz processor (TJ85, 2.0-MB L2 cache, Dual Core, 35 W, TDP;

includes replacement thermal material)

653338-001 Intel Pentium B950 2.10-GHz processor (TJ85, 2.0-MB L2 cache, Dual Core, 35 W, TDP;

includes replacement thermal material)

653339-001 Intel Core i3-2330M 2.20-GHz processor (3.0-MB L3 cache, Dual Core, 35 W; includes

replacement thermal material)

653340-001 Intel Core i3-2350M 2.30-GHz processor (3.0-MB L3 cache, dual core, 35 W; includes

replacement thermal material)

653341-001 Intel Core i5-2430M 2.40-GHz (SC turbo up to 3.00-GHz) processor (3.0-MB L3 cache,

dual core, 35 W; includes replacement thermal material)

653348-001 AMD Sabine A4-3300M 2.5-GHz processor (1.9-GHz FSB, 2.0-MB L2 cache, Dual Core, 35 W;

includes replacement thermal material)

653349-001 AMD Sabine A6-3400M 2.3-GHz processor (1.4-GHz FSB, 4.0-MB L2 cache, Quad Core,

35 W; includes replacement thermal material)

653350-001 AMD Sabine A8-3500M 2.4-GHz processor (1.5-GHz FSB, 4.0-MB L2 cache, Quad Core,

35 W; includes replacement thermal material)

653356-001 AMD Sabine A4-3310MX 2.5-GHz processor (2.1-GHz FSB, 2.0-MB L2 cache, Dual Core,

45 W; includes replacement thermal material)

653357-001 AMD Sabine A6-3410MX 2.3-GHz processor (1.6-GHz FSB, 4.0-MB L2 cache, Quad Core,

45 W; includes replacement thermal material)

653358-001 AMD Sabine A8-3510MX 2.5-GHz processor (1.8-GHz FSB, 4.0-MB L2 cache, Quad Core,

45 W; includes replacement thermal material)

653364-001 AMD Sabine A8-3530MX 2.6-GHz processor (1.9-GHz FSB, 4.0-MB L2 cache, Quad Core,

45 W; includes replacement thermal material)

653426-001 Heat sink for use only with computer models equipped with an AMD processor and a graphics

subsystem with discrete video memory (includes replacement thermal material)

653427-001 System board for use only with computer models equipped with an AMD processor and a

graphics subsystem with discrete video memory (includes 1-GB of graphics subsystem memory

and replacement thermal material)

653428-001 System board for use only with computer models equipped with an AMD processor and a

graphics subsystem with UMA video memory (includes replacement thermal material)

653525-001 Hard Drive Hardware Kit (includes hard drive bracket and screws)

NOTE: See

Mass storage devices on page 26 for more Hard Drive Hardware Kit information.

32 Chapter 3 Illustrated parts catalog

Other manuals for HP Pavilion dv4

Product End-Of-Life Disassembly Instructions4 pages

Questions and Answers:

Need help?

Do you have a question about the HP Pavilion dv4 and is the answer not in the manual?

HP Pavilion dv4 Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	8 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	750 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card memory	1.696 GB
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	Beats Audio
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Trial software	Norton Internet Security 2011
Bundled software	Adobe Reader\\r Adobe Shockwave Player\\r Adobe Flash Player\\r Evernote\\r Microsoft Silverlight\\r HP CoolSense\\r HP ProtectSmart\\r HP Launch Box\\r Microsoft Office Starter\\r Windows Live Essentials 2011\\r Windows Live Mail\\r Windows Live Messenger\\r Windows Live Photo Gallery\\r Windows Live Movie Maker\\r Windows Live Writer\\r Windows Live Mesh\\r HP MyRoom\\r Internet Explorer 9\\r Skype\\r Bing Bar f/ Internet Explorer 9
Operating system installed	Windows 7 Home Premium
Form factor	Clamshell
Product type	Laptop
Country of origin	China
Battery capacity	62 Wh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
Processor code	SR0N0
Processor ARK ID	65708
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
