Right-side components
Component Description
(1)
Audio-out (headphone) jack
Produces system sound when connected to optional powered stereo
speakers, headphones, ear buds, a headset, or television audio.
NOTE On select models, the headphone jack can also be used to
output S/PDIF digital audio.
(2)
Audio-in (microphone) jack
Connects an optional computer headset microphone or a microphone.
(3)
ExpressCard slot
Supports optional ExpressCard/54 or ExpressCard/34 cards.
(4)
USB port (select models only)
Connects an optional USB device.
(5)
Optical drive
Reads an optical disc.
(6)
RJ-11 (modem) jack
Connects a modem cable.
(7)
Power connector
Connects an AC adapter or an optional power adapter.
8 Chapter 1 Notebook Tour ENWW
