16.0-inch WXGA BrightView display specifications
Metric U.S.
Dimensions
Height
21.4 cm 8.4 in
Width 36.5 cm 14.4 in
Diagonal 40.6 cm 16 in
Number of colors Up to 262,000
Contrast ratio 600:1 (typical)
Brightness 200 nits (typical)
Pitch resolution
Pitch
0.259 × 0.259 mm
Format 1366 × 768
Configuration RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power consumption 4.5 W
Viewing angle ±45° horizontal, ±20° upper vertical, ±45° lower vertical (typical)
116 Chapter 6 Specifications
