System DMA specifications
Hardware DMA
System function
DMA0
Not applicable
DMA1*
Not applicable
DMA2*
Not applicable
DMA3
Not applicable
DMA4
Direct memory
access con
troller
DMA5*
Available for ExpressCard
DMA6
Not assigned
DMA7
Not assigned
*ExpressCard controller can use DMA 1, 2, or 5.
