TV tuner module
NOTE: The TV tuner module spare part kit does not include a TV tuner module cable. The TV tuner
module cable is included in the Cable Kit, spare part number 512832-001.
NOTE: The TV tuner external antenna cables are available using spare part numbers 482900-001
(with F-PAL jack) and 482900-002 (with PAL jack).
Description Spare part number
DVB-T TV tuner module (for use only with computers equipped with discrete graphics memory) 482899-003
DVB-T/ANG TV tuner module 482899-002
NTSC/ATSC/ANG hybrid TV tuner module 482899-001
TV tuner external antenna cable with F-PAL jack 482900–001
TV tuner external antenna cable with PAL jack 482900–002
Before removing the TV tuner module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC Adapter from the computer.
4. Remove the battery (see
Battery on page 59).
5. Remove the memory module compartment cover (see
Memory module on page 64).
Remove the TV tuner module:
1. Disconnect the TV tuner module antenna cable (1) from the terminal on the TV tuner module.
2. Remove the Phillips PM2.0×3.0 screw (2) that secures the TV tuner module to the computer.
66 Chapter 4 Removal and replacement procedures
