Top cover
NOTE: The top cover spare part kit includes TouchPad and TouchPad buttons, and speaker assembly.
Description Spare part number
Top cover for use only with computer models equipped with a fingerprint reader, Onyx 512828-001
Top cover for use only with computer models not equipped with a fingerprint reader, Onyx 511888-001
Top cover for or use only with computer models equipped with a fingerprint reader, Moonlight White 518108-001
Top cover for use only with computer models not equipped with a fingerprint reader, Moonlight White 518109-001
For use only with computer models equipped with a fingerprint reader, Espresso Black 518788-001
For use only with computer models not equipped with a fingerprint reader, Espresso Black 518789-001
Before removing the top cover, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 59).
5. Remove the following components:
a. Hard drive (see
Hard drive on page 69)
b. Optical drive (see
Optical drive on page 62)
c. Switch cover and keyboard (see
Switch cover and keyboard on page 76)
d. Display assembly (see
Display assembly on page 81)
Remove the top cover:
1. Turn the computer upside down, with the front toward you.
2. Remove the 9 Phillips PM2.5×6.5 screws (1) that secure the top cover to the computer.
Component replacement procedures 91
