Removal and replacement procedures
Maintenance and Service Guide 4–27
10. If it is necessary to replace the display inverter, release the display inverter 1 as far from the display enclosure
as the display panel cable and backlight cable allow.
11. Disconnect the display panel cable 2 and the backlight cable 3 from the display inverter.
12. Remove the display inverter. The display inverter is available using spare part number 488317-001.
