Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(5) Fingerprint reader
NOTE: The ngerprint reader cable is available in the Cable Kit as spare part number
M45391-001.
M45007-001
(6) Fingerprint reader bracket not available as a spare part
(7) Speakers (left and right) M45122-001
(8) System board (includes integrated processor)
Intel Core i7-1165G7 M45125-601
Intel Core i5-1135G7 M45124-601
Intel Core i3-1125G4 M46656-601
Intel Core i3-1115G4 M45123-601
Intel Pentium Gold 7505 M45126-601
(9) Fan M45131-001
(10) Heat sink (includes replacement thermal material) M45132-001
(11) Memory modules (DDR4, PC-3200)
8 GB L46598-005
4 GB L83673-005
(12) Memory cover not available as a spare part
(13) WLAN module
Intel Wi-Fi 6 AX201 802.11ax (2 × 2) and Bluetooth 5 (non-vPro) L92724-005
Intel Wireless-AC 9461 802.11ac 1 × 1 Wi-Fi + Bluetooth 5 L25889-005
Realtek Wi-Fi 6 RTL8852AE-VT + Bluetooth 5.2 M34029-005
(14) Power connector cable M45022-001
(15) Solid-state drive (PCIe)
NOTE: The thermal pad for use with solid-state drives are available as spare part
number M45025-001.
1 TB L85370-005
512 GB L85364-005
512 GB, PCIe + 32 GB Optane memory L85366-005
256 GB, PCIe L85354-005
256 GB, PCIe + 16 GB Optane memory L85356-005
(16) Solid-state drive cover not available as a spare part
(17) Battery (3 cell, 43 Whr) M24648-006
(18) Bottom cover M45109-001
(19) Rubber feet M45110-001
Computer major components 17
