3. Remove the Phillips M2.0 × 2.5 screw (3), and then remove the WLAN module (4).
4. If the WLAN antenna is not connected to the terminal on the WLAN module, install a protective sleeve on
the antenna connector, as shown in the following illustration.
Reverse this procedure to install the WLAN module.
Speakers
To remove the speakers, use this procedure and illustration.
Table 5-6
Speaker description and part number
Description Spare part number
Speaker Kit M45122-001
Speakers 37
