Front Panel Components
Drive configuration may vary by model.
Figure 1-3 Front Panel Components
Table 1-1 Front Panel Components
1
5.25-inch Optical Drive
1
6 Hard Drive Activity Light
2 5.25-inch Optical Drive Bay 7 Optical Drive Eject Button
3
3.5-inch Media Card Reader (optional)
2
8 Microphone Connector
4 Recovery/Reset Button 9 Headphone Connector
5 Dual-State Power Button 10 USB (Universal Serial Bus) 2.0 Ports
1
Some models have bezel blanks covering one or both of the 5.25-inch drive bays.
2
Some models have a bezel blank covering the 3.5-inch drive bay.
Front Panel Components 3
