Memory
Description Spare part number
4-GB, PC3-10600 585157-001
2-GB, PC3-10600 635803-001
1-GB, PC3-10600 635802-001
The computer comes with double data rate 3 synchronous dynamic random access memory (DDR3-
SDRAM) dual inline memory modules (DIMMs).
DDR3-SDRAM DIMMs
There are two DIMM slots on the system board.
●
HP Pro 3330/3380: 2 DIMM slots, 8 GB max
●
HP Pro 3340/3348: 2 DIMM slots, 8 GB max
●
HP Pro 3335/3385: 4 DIMM slots, 16 GB max
These memory sockets are populated with at least one preinstalled DIMM. To achieve the maximum
memory support, you can populate the system board with up to 8 GB of memory for Intel models or
16 GB for AMD models.
Figure 7-5 DIMM Socket Locations — HP Pro 3330/3380
Table 7-1 DIMM Socket Locations — HP Pro 3330/3380
Description Socket Color Insertion Order
XMM1 socket, Channel A (populate first) Black 1
Memory 53
