Figure 7-28 Optical drive alignment hole
Removing a Hard Drive
NOTE: Before you remove the old hard drive, be sure to back up the data from the old hard drive so
that you can transfer the data to the new hard drive. Also, if you are replacing the primary hard drive,
make sure you have created a Recovery Disc Set to restore the operating system, software drivers,
and any software applications that were preinstalled on the computer.
1. Prepare the computer for disassembly (Preparation for Disassembly on page 48).
2. Remove the access panel (
Access Panel on page 49).
76 Chapter 7 Removal and Replacement Procedures – Microtower (MT) Chassis
