Item Component Spare part number
(6a) WLAN auxiliary transceiver and cable
(6b) WLAN main transceiver and cable
For use only on HP Pro Slate 10 EE G1 tablet models 803379-001
For use only on HP Pro Tablet 10 EE G1 tablet models 804221-001
(7) WWAN module:
Huawei MU736 3G HSPA+M.2 with GPS for use only on HP Pro Slate 10 EE G1 tablet models 801160-005
MU736 HS3110 Gen HSPA+m.2 with GPS for use only on HP Pro Tablet 10 EE G1
tablet models
748599-005
(8) 5.0-MP, HD rear-facing webcam with auto-focus (includes cable and double-
sided adhesive)
802825-001
(9) Speaker (includes speaker and cable) 802830-001
(10) Transfer board (includes cable) 802848-001
(11) Display panel cable – included in the Cable Kit, spare part number 802835-001.
(12) System board:
For use only on HP Pro Slate 10 EE G1 tablet models (all system boards equipped with the Android 4.4.4
operating system):
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem
with UMA memory, 2.0-GB of system memory, 16-GB of system storage, NFC, and
WWAN capability
802837-001
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem
with UMA memory, 2.0-GB of system memory, 32-GB of system storage, NFC, and
WWAN capability
802838-001
Equipped with an Intel Atom Z3735G 1.83-GHz processor (quad core), a graphics subsystem
with UMA memory, 1.0-GB of system memory, 16-GB of system storage, and
WWAN capability
802839-001
Equipped with an Intel Atom Z3735G 1.83-GHz processor (quad core), a graphics subsystem
with UMA memory, 1.0-GB of system memory, 32-GB of system storage, and
WWAN capability
802840-001
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem
with UMA memory, 2.0-GB of system memory, 16-GB of system storage, NFC, and
GPS capability
802841-001
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem
with UMA memory, 2.0-GB of system memory, 32-GB of system storage, NFC, and
GPS capability
802842-001
Equipped with an Intel Atom Z3735G 1.83-GHz processor (quad core), a graphics subsystem
with UMA memory, 1.0-GB of system memory, 16-GB of system storage, and GPS capability
802843-001
Equipped with an Intel Atom Z3735G 1.83-GHz processor (quad core), a graphics subsystem
with UMA memory, 1.0-GB of system memory, 32-GB of system storage, and GPS capability
803396-001
For use only on HP Pro Tablet 10 EE G1 tablet models:
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem
with UMA memory, 2.0-GB of system memory, 32-GB of system storage, and the Windows
8 Professional operating system
803370-601
8 Chapter 3 Illustrated parts catalog

HP Pro Slate 10 EE G1 Specifications

General

Stepping	C0
Processor code	SR1UB
Processor cache	2 MB
Processor cores	4
Processor model	Z3735F
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z3700 Series
Processor codename	Bay Trail
Processor frequency	1.33 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	17 x 17 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	1.83 GHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
Thermal Design Power (TDP)	- W
Scenario Design Power (SDP)	2.2 W
Processor ARK ID	80274
Processor socket	BGA 592
Internal memory	2 GB
Internal memory type	DDR3L-SDRAM
Storage media	Flash
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Internal storage capacity	32 GB
Display diagonal	10.1 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 800 pixels
Graphics card	HD Graphics
Rear camera type	Single camera
Maximum video resolution	- pixels
Rear camera resolution (numeric)	- MP
Audio system	DTS Sound+
Number of built-in speakers	1
WWAN	Installed
3G standards	HSPA+
Ethernet LAN	No
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Mobile network generation	3G
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
Country of origin	China
Device type	Mobile tablet
Form factor	Slate
Product color	Black
Sustainability certificates	RoHS, ENERGY STAR
Battery capacity	28.5 Wh
Battery life (max)	- h
Number of battery cells	2
Continuous video playback time	9.5 h
AC adapter power	18 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Operating system version	4.4 KitKat
Operating system installed	Android
Operating shock	40 G
Operating altitude	0 - 5000 m
Non-operating shock	240 G
Operating vibration	1.043 G
Non-operating altitude	0 - 12192 m
Non-operating vibration	3.5 G
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	182 mm
Width	280 mm
Height	14.4 mm
Weight	855 g
