6 Using Computer Setup (BIOS) in Windows 10
Using Computer Setup
Computer Setup, or Basic Input/Output System (BIOS), controls communication between all the input and
output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Computer Setup
includes settings for the types of devices installed, the startup sequence of the computer, and the amount of
system and extended memory.
NOTE: Use extreme care when making changes in Computer Setup. Errors can prevent the computer from
operating properly.
Starting Computer Setup
NOTE: An external keyboard or mouse connected to a USB port can be used with Computer Setup only if USB
legacy support is enabled.
To start Computer Setup, follow these steps:
▲
Start Computer Setup.
●
Computers or tablets with keyboards:
▲
Turn on or restart the computer, and when the HP logo appears, press f10 to enter Computer
Setup.
●
Tablets without keyboards:
▲
Turn o the tablet. Press the power button in combination with the volume down button until
the Startup menu is displayed, and then tap F10 to enter Computer Setup.
Navigating and selecting in Computer Setup
●
To select a menu or a menu item, use the tab key and the keyboard arrow keys and then press enter, or
use a pointing device to select the item.
NOTE: On tablets without keyboards, you can use your nger to make selections.
●
To scroll up and down, select the up arrow or the down arrow in the upper-right corner of the screen, or
use the up arrow key or the down arrow key on the keyboard.
●
To close open dialog boxes and return to the main Computer Setup screen, press esc, and then follow
the on-screen instructions.
To exit Computer Setup menus, choose one of the following methods:
●
To exit Computer Setup menus without saving your changes:
Select the Exit icon in the lower-right corner of the screen, and then follow the on-screen instructions.
– or –
Select Main, select Ignore Changes and Exit, and then press enter.
●
To save your changes and exit Computer Setup menus:
46 Chapter 6 Using Computer Setup (BIOS) in Windows 10

HP Pro Slate 10 EE G1 Specifications

General

Stepping	C0
Processor code	SR1UB
Processor cache	2 MB
Processor cores	4
Processor model	Z3735F
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z3700 Series
Processor codename	Bay Trail
Processor frequency	1.33 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	17 x 17 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	1.83 GHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
Thermal Design Power (TDP)	- W
Scenario Design Power (SDP)	2.2 W
Processor ARK ID	80274
Processor socket	BGA 592
Internal memory	2 GB
Internal memory type	DDR3L-SDRAM
Storage media	Flash
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Internal storage capacity	32 GB
Display diagonal	10.1 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 800 pixels
Graphics card	HD Graphics
Rear camera type	Single camera
Maximum video resolution	- pixels
Rear camera resolution (numeric)	- MP
Audio system	DTS Sound+
Number of built-in speakers	1
WWAN	Installed
3G standards	HSPA+
Ethernet LAN	No
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Mobile network generation	3G
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
Country of origin	China
Device type	Mobile tablet
Form factor	Slate
Product color	Black
Sustainability certificates	RoHS, ENERGY STAR
Battery capacity	28.5 Wh
Battery life (max)	- h
Number of battery cells	2
Continuous video playback time	9.5 h
AC adapter power	18 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Operating system version	4.4 KitKat
Operating system installed	Android
Operating shock	40 G
Operating altitude	0 - 5000 m
Non-operating shock	240 G
Operating vibration	1.043 G
Non-operating altitude	0 - 12192 m
Non-operating vibration	3.5 G
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	182 mm
Width	280 mm
Height	14.4 mm
Weight	855 g
