Page #48 background image
System board
Description Spare part number
For use only on HP Pro Slate 10 EE G1 tablet models (all system boards equipped with the Android 4.4.4 operating system):
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 16-GB of system storage, NFC, and WWAN capability
802837-001
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 32-GB of system storage, NFC, and WWAN capability
802838-001
Equipped with an Intel Atom Z3735G 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 1.0-GB of system memory, 16-GB of system storage, and WWAN capability
802839-001
Equipped with an Intel Atom Z3735G 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 1.0-GB of system memory, 32-GB of system storage, and WWAN capability
802840-001
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 16-GB of system storage, NFC, and GPS capability
802841-001
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 32-GB of system storage, NFC, and GPS capability
802842-001
Equipped with an Intel Atom Z3735G 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 1.0-GB of system memory, and 16-GB of system storage, and GPS capability
802843-001
Equipped with an Intel Atom Z3735G 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 1.0-GB of system memory, 32-GB of system storage, and GPS capability
803396-001
For use only on HP Pro Tablet 10 EE G1 tablet models:
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 32-GB of system storage, and the Windows 8 Professional
operating system
803370-601
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 32-GB of system storage, and the Windows 8 Standard
operating system
803370-501
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 32-GB of system storage, and a non-Windows 8 operating system
803370-001
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 32-GB of system storage, WWAN capability, and the Windows 8
Professional operating system
803371-601
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 32-GB of system storage, WWAN capability, and the Windows 8
Standard operating system
803371-501
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 32-GB of system storage, WWAN capability, and a non-Windows 8
operating system
803371-001
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 64-GB of system storage, and the Windows 8 Professional
operating system
803372-601
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 64-GB of system storage, and the Windows 8 Standard
operating system
803372-501
Equipped with an Intel Atom Z3735F 1.83-GHz processor (quad core), a graphics subsystem with UMA
memory, 2.0-GB of system memory, 64-GB of system storage, and a non-Windows 8 operating system
803372-001
40 Chapter 5 Removal and replacement procedures

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pro Slate 10 EE G1 and is the answer not in the manual?

HP Pro Slate 10 EE G1 Specifications

General IconGeneral
SteppingC0
Processor codeSR1UB
Processor cache2 MB
Processor cores4
Processor modelZ3735F
System bus rate- GT/s
Processor familyIntel Atom®
Processor seriesIntel Atom Z3700 Series
Processor codenameBay Trail
Processor frequency1.33 GHz
Processor cache typeL2
Processor manufacturerIntel
Processor package size17 x 17 mm
Conflict-Free processorYes
Processor front side bus- MHz
Processor boost frequency1.83 GHz
Processor operating modes32-bit, 64-bit
Graphics & IMC lithography22 nm
Thermal Design Power (TDP)- W
Scenario Design Power (SDP)2.2 W
Processor ARK ID80274
Processor socketBGA 592
Internal memory2 GB
Internal memory typeDDR3L-SDRAM
Storage mediaFlash
Compatible memory cardsMicroSD (TransFlash), MicroSDHC
Internal storage capacity32 GB
Display diagonal10.1 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display resolution1280 x 800 pixels
Graphics cardHD Graphics
Rear camera typeSingle camera
Maximum video resolution- pixels
Rear camera resolution (numeric)- MP
Audio systemDTS Sound+
Number of built-in speakers1
WWANInstalled
3G standardsHSPA+
Ethernet LANNo
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 4 (802.11n)
Mobile network generation3G
Headphone connectivity3.5 mm
USB 2.0 ports quantity-
Country of originChina
Device typeMobile tablet
Form factorSlate
Product colorBlack
Sustainability certificatesRoHS, ENERGY STAR
Battery capacity28.5 Wh
Battery life (max)- h
Number of battery cells2
Continuous video playback time9.5 h
AC adapter power18 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
Operating system version4.4 KitKat
Operating system installedAndroid
Operating shock40 G
Operating altitude0 - 5000 m
Non-operating shock240 G
Operating vibration1.043 G
Non-operating altitude0 - 12192 m
Non-operating vibration3.5 G
Storage temperature (T-T)-20 - 65 °C
Operating temperature (T-T)0 - 50 °C
Storage relative humidity (H-H)0 - 95 %
Operating relative humidity (H-H)0 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth182 mm
Width280 mm
Height14.4 mm
Weight855 g
