1. Disconnect the power connector cable (1) from the system board.
2. Release the power connector cable from the retention clip (2) built into the display panel assembly.
3. Remove the two Phillips PM2.0×4.1 screws (3) that secure the power connector to the display
panel assembly.
4. Remove the power connector cable (4).
Reverse this procedure to install the power connector cable.
Front-facing webcam
Description Spare part number
Front-facing webcam (includes cable) 802826-001
Before removing the front-facing webcam, follow these steps:
1. Turn o the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 23).
5. Disconnect the battery cable from the system board (see Battery on page 24).
Remove the front-facing webcam:
Front-facing webcam 35
