HP Pro Slate 10 EE G1 User Manual

8 Using HP PC Hardware Diagnostics (UEFI) in
Windows 8.1
HP PC Hardware Diagnostics is a Unied Extensible Firmware Interface (UEFI) that allows you to run diagnostic
tests to determine whether the tablet hardware is functioning properly. The tool runs outside the operating
system so that it can isolate hardware failures from issues that are caused by the operating system or other
software components.
To start HP PC Hardware Diagnostics (UEFI):
1. Turn o the tablet.
2. Press and hold the Power and Volume down buttons at the same time until the tablet turns on and
“Esc…pause at startup” is displayed at the bottom of the screen.
The Startup menu is displayed.
3. Select System Diagnostics.
4. When the diagnostic tool opens, select the type of diagnostic test you want to run, and then follow the
on-screen instructions.
NOTE: If you need to stop a diagnostic test, press esc.
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device
NOTE: Instructions for downloading HP PC Hardware Diagnostics (UEFI) are provided in English only.
There are two options to download HP PC Hardware Diagnostics to a USB device:
Option 1: HP PC Diagnostics home page— Provides access to the latest UEFI version
1. Go to http://hp.com/go/techcenter/pcdiags.
2. Tap the UEFI Download link, and then select Run.
Option 2: Support and Drivers pages—Provide downloads for a specic product for earlier and later versions
1. Go to http://www.hp.com.
2. Tap Support, located at the top of the page, and then tap Download Drivers.
3. In the text box, enter the product name, and then tap Go.
– or –
Tap Find Now to let HP automatically detect your product.
4. In the Diagnostic section, tap HP UEFI Support Environment.
– or –
Tap Download, and then select Run.
52 Chapter 8 Using HP PC Hardware Diagnostics (UEFI) in Windows 8.1

HP Pro Slate 10 EE G1 Specifications

General

Stepping	C0
Processor code	SR1UB
Processor cache	2 MB
Processor cores	4
Processor model	Z3735F
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z3700 Series
Processor codename	Bay Trail
Processor frequency	1.33 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	17 x 17 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	1.83 GHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
Thermal Design Power (TDP)	- W
Scenario Design Power (SDP)	2.2 W
Processor ARK ID	80274
Processor socket	BGA 592
Internal memory	2 GB
Internal memory type	DDR3L-SDRAM
Storage media	Flash
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Internal storage capacity	32 GB
Display diagonal	10.1 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 800 pixels
Graphics card	HD Graphics
Rear camera type	Single camera
Maximum video resolution	- pixels
Rear camera resolution (numeric)	- MP
Audio system	DTS Sound+
Number of built-in speakers	1
WWAN	Installed
3G standards	HSPA+
Ethernet LAN	No
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Mobile network generation	3G
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
Country of origin	China
Device type	Mobile tablet
Form factor	Slate
Product color	Black
Sustainability certificates	RoHS, ENERGY STAR
Battery capacity	28.5 Wh
Battery life (max)	- h
Number of battery cells	2
Continuous video playback time	9.5 h
AC adapter power	18 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Operating system version	4.4 KitKat
Operating system installed	Android
Operating shock	40 G
Operating altitude	0 - 5000 m
Non-operating shock	240 G
Operating vibration	1.043 G
Non-operating altitude	0 - 12192 m
Non-operating vibration	3.5 G
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	182 mm
Width	280 mm
Height	14.4 mm
Weight	855 g
