2. Lift and remove the right speaker (2).
Reverse this procedure to install the right speaker.
Battery and middle plate
Description Spare part number
Battery and middle plate for models without WWAN capability, 21 Whr, 1S2P, Lithium-polymer, non-
user removable
823039-001
Battery and middle plate for models with WWAN capability, 21 Whr, 1S2P, Lithium-polymer, non-user
removable
823040-001
Before removing the battery, follow these steps:
1. Turn o the tablet. If you are unsure whether the tablet is o, turn the tablet on, and then shut it down
through the operating system.
2. Disconnect the power from the tablet by unplugging the power adapter cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the MicroSD card tray (see MicroSD card tray on page 17).
5. Remove the Nano SIM card tray (select products only) (see Nano SIM card tray (select models only)
on page 18.
6. Remove the back cover (see Back cover on page 18).
7. Disconnect the battery (see Disconnecting the battery on page 19).
36 Chapter 5 Removal and replacement procedures
