j. Top cover (see Top cover on page 53)
k. System board (see
System board on page 66)
l. Heat sink (see
Heat sink on page 69)
Remove the processor:
1. Position the system board face up with the front toward you.
2. Use a flat-bladed screwdriver to turn the processor locking screw (1) one-half turn
counterclockwise until you hear a click.
3. Lift the processor (2) straight up and remove it.
NOTE: The gold triangle (3) on the processor must be aligned with the triangle (4) embossed
on the processor slot when you install the processor.
Reverse this procedure to install the processor.
Component replacement procedures 73
