Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
Table 3-2 Display component descriptions and part numbers
Item Component Spare part number
(1) Display bezel
For use in models with an FHD display and without a camera M21991-001
For use in models with an FHD display and with a 5 MP camera M21992-001
For use in models with an FHD display and with a 5 MP + IR camera N39024-001
For use in models with an HD display and without a camera N14641-001
For use in models with an HD display and with a camera N07351-001
22 Chapter 3 Illustrated parts catalog
