Table 10-2 Display specifications
Metric U.S.
Active diagonal size 39.6 cm 15.6 in
Resolution 1366 × 768 (HD)
1920 × 1080 (FHD)
2560 × 1440 (QHD)
Surface treatment Antiglare
Brightness 250 nits
300 nits
400 nits
Viewing angle UWVA
Backlight LED
Display panel interface eDP
Solid-state drive specifications
This section provides specifications for your solid-state drives.
Table 10-3
Solid-state drive specifications
256 GB* 512 GB* 1 TB*
Dimensions
Height 1.0 mm 1.0 mm 1.0 mm
Length 50.8 mm 50.8 mm 50.8 mm
Width 28.9 mm 28.9 mm 28.9 mm
Weight < 10 g < 10 g < 10 g
Interface type PCIe PCIe PCIe
Ready time, maximum (to not busy) 1.0 ms < 1.0 ms 1.0 ms
Access times, logical 0.1 ms 0.1 ms 0.1 ms
Transfer rate
Sequential read up to 2150 MBps up to 2150 MBps up to 2150 MBps
Random read Up to 300,000 IOPs Up to 300,000 IOPs Up to 300,000 IOPs
Sequential write up to 1550 MBps up to 1550 MBps up to 1550 MBps
Random write Up to 100,000 IOPs Up to 100,000 IOPs Up to 100,000 IOPs
Total logical sectors 468,883,296 1,000,215,216 1,500,336,388
Operating temperature 0°C to 70°C (32°F to 158°F)
*1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less. Actual drive
specifications might differ slightly.
Solid-state drive specifications 83
