Descriptions
HP Procurve Switch GL Modules
For the HP Procurve Switch 4108GL
Descriptions
The HP Procurve Switch GL Modules are components that you can add to an
HP Procurve GL switch to provide a variety of network connectivity options.
The following modules are available as of this printing:
Contact your HP-authorized networking products reseller or your HP repre-
sentative for information on availability of other modules and transceivers.
You can also visit the HP networking products Web site at http://www.hp.com/
go/hpprocurve to get more information.
Module Description
HP Procurve Switch
10/100-T GL Module
(HP J4862A)
24 twisted-pair ports with RJ-45
connectors for 10 Mbps or 100
Mbps operation over 100-ohm
unshielded (UTP) or shielded (STP)
twisted-pair cable -- all ports have
the HP Auto-MDIX feature
HP Procurve Switch
100/1000-T GL Module
(HP J4863A)
6 twisted-pair ports with RJ-45
connectors for 1000 Mbps
(Gigabit) or 100 Mbps operation
over Category 5 or better 100-ohm
UTP or STP cable (category 5E
recommended for Gigabit) -- all
ports have the IEEE 802.3ab Auto
MDI/MDI-X feature
HP Procurve Switch
Gigabit Transceiver GL
Module (HP J4864A)
3 transceiver slots for installing
any of the supported HP Procurve
transceivers*.
* The following HP Procurve transceivers are supported by the Gigabit Transceiver GL Module (as of this printing):
• 100-FX Transceiver (HP J4853A)
• Gigabit-SX Transceiver (HP J4131A)
• Gigabit-LX Transceiver (HP J4132A)
• 100/1000-T Transceiver (HP J4834A)
• Gigabit Stacking (part of the HP Procurve Switch Gigabit Stacking Kit -- HP J4116A)
Remove network cable before removing or installing transceiver
