Front panel components
Drive conguration may vary by model. Some models have a bezel blank covering the slim optical drive bay.
NOTE: Refer to the illustration that most closely matches your computer.
1 Slim optical drive (optional) 4 Audio-out (headphone)/Audio-in (microphone) combo
jack
2 Dual-state power button 5 USB SuperSpeed ports (2)*
3 Hard drive activity light 6 Memory card reader
*This port connects a USB device, provides high-speed data transfer, and even when the computer is o, charges products
such as a cell phone, camera, activity tracker, or smartwatch.
NOTE: When a device is plugged into the combo jack, a dialog box is displayed. Select the type of device that is connected.
Front panel components 3
