Front bezel
Description
Front bezel for use in all countries and regions except for the People’s Republic of China
Front bezel for use in the People’s Republic of China
1. Prepare the computer for disassembly (Preparation for disassembly on page 23).
2. Remove the access panel (
Access panel on page 24)
3. Lift up the three tabs on the side of the bezel (1), then rotate the bezel off the chassis (2).
Front bezel 25
