WLAN module
Description
HP WLAN 802.11 a/b/g/n + Bluetooth 4.0
Intel Dual Band Wireless-N 7260NB 802.11 a/b/g/n 2x2 WiFi + BT4.0
You can install a WLAN module using a PCIe expansion card. The module is secured to the expansion card
with two Phillips screw and has two connected antennas.
To remove the WLAN module:
1. Prepare the computer for disassembly (
Preparation for disassembly on page 23)
2. Remove the access panel (
Access panel on page 24)
3. If replacing a WLAN module, remove the PCIe card that houses the module (
Expansion cards
on page 29). Go to step 4.
- or -
If installing a WLAN module, connect the module to the PCIe card, and then install the PCIe card in the
computer (
Expansion cards on page 29). Go to step 7.
4. To remove a WLAN module, disconnect the antenna cables from the module (1).
42 Chapter 5 Removal and replacement procedures: Microtower
