After the Windows 7 operating system DVD has been created, create the Driver Recovery DVD:
1. Select Start > All Programs > Productivity and Tools > HP Recovery Disc Creator.
2. Select Driver disk.
3. From the drop-down menu, select the drive for burning the recovery media.
4. Click the Create button to start the burning process. Label the disc after you create it, and store it
in a secure place.
Backing up your information
You should create your initial backup immediately after initial system setup. As you add new software
and data files, you should continue to back up your system on a regular basis to maintain a reasonably
current backup. Your initial and subsequent backups allow you to restore your data and settings if a
failure occurs.
You can back up your information to an optional external hard drive, a network drive, or discs.
Note the following when backing up:
Store personal files in the Documents library, and back it up regularly.
Back up templates that are stored in their associated directories.
Save customized settings that appear in a window, toolbar, or menu bar by taking a screen shot
of your settings. The screen shot can be a time-saver if you have to reset your preferences.
When backing up to discs, number each disc after removing it from the drive.
NOTE: For detailed instructions on various backup and restore options, perform a search for these
topics in Help and Support. To access Help and Support, select Start > Help and Support.
NOTE: You may be prompted by User Account Control for your permission or password when you
perform certain tasks. To continue a task, select the appropriate option. For information about User
Account Control, see Help and Support: Select Start > Help and Support.
To create a backup using Windows Backup and Restore:
NOTE: The backup process may take over an hour, depending on file size and the speed of the
computer.
1. Select Start > All Programs > Maintenance > Backup and Restore.
2. Follow the on-screen instructions to set up your backup.
System Restore
If you have a problem that might be due to software that you installed on your computer, or if you want
to restore the system to a previous state without losing any personal information, use System Restore to
return the computer to a previous restore point.
NOTE: Always use this System Restore procedure before you use the System Recovery feature.
Backing up, restoring, and recovering in Windows 7
215

Table of Contents

Other manuals for HP ProDesk 490 G1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProDesk 490 G1 and is the answer not in the manual?

HP ProDesk 490 G1 Specifications

General IconGeneral
Tcase72.72 °C
Bus typeDMI2
SteppingC0
Processor cache8 MB
Processor cores4
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-4700 Desktop series
Processor socketLGA 1150 (Socket H3)
Processor threads8
Processor codenameHaswell
Processor frequency3.4 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.9 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)84 W
Number of processors installed1
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory voltage supported by processor1.5 V
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Memory slots4x DIMM
Internal memory16 GB
Memory channelsDual-channel
Memory clock speed1600 MHz
Maximum internal memory- GB
HDD size3.5 \
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Card reader integratedYes
Total storage capacity1000 GB
Intel segment taggingEnterprise, Small Business
Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
On-board graphics card ID0x412
Discrete graphics card modelNVIDIA® GeForce® GT 630
On-board graphics card modelIntel® HD Graphics 4600
Discrete graphics card memory2048 GB
Discrete graphics memory typeGDDR3
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory2 GB
On-board graphics card OpenGL version4.3
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version11.2/12
On-board graphics card dynamic frequency (max)1200 MHz
Number of displays supported (on-board graphics)3
Bundled softwareHP Client Security\\r HP Trust Circles Standard\\r HP Wireless HotSpot\\r HP PageLift\\r HP Recovery Manager\\r HP Support Assistant\\r HP ePrint\\r CyberLink PowerDVD\\r CyberLink Power2Go\\r Buy Office
Recovery operating systemWindows 8.1 Pro
Operating system installedWindows 7 Professional
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
HDMI ports quantity0
PS/2 ports quantity2
USB 2.0 ports quantity6
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Audio systemRealtek ALC221
Product typePC
Motherboard chipsetIntel® H87
Scalability1S
Processor codeSR149
Processor ARK ID75122
Intel TSX-NI version0.00
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal solution specificationPCG 2013D
Intel Identity Protection Technology version1.00
Power supply300 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth402 mm
Width182.8 mm
Height357 mm
Weight7140 g
