Page #227 background imageLoading...
Page #227 background image
4. When Windows has loaded, click the Start button, and then click All Programs.
If Security and Protection is listed, continue with step
5.
If Productivity and Tools is listed, follow the steps in
System Recovery when Windows is
not responding on page 217.
5. Click Security and Protection, click Recovery Manager, and then click Recovery
Manager. If prompted, click Yes to allow the program to continue.
6. Under I need help immediately, click System Recovery.
7. Select Yes, and then click Next. Your computer restarts.
8. When the computer restarts, you will see the Recovery Manager welcome screen again. Under I
need help immediately, click System Recovery. If you are prompted to back up your files,
and you have not done so, select Back up your files first (recommended), and then click
Next. Otherwise, select Recover without backing up your files, and then click Next.
9. System Recovery begins. After System Recovery is complete, click Finish to restart the computer.
10. When Windows has loaded, shut down the computer, reconnect all peripheral devices, and then
turn the computer back on.
System Recovery when Windows is not responding
CAUTION: System Recovery deletes all data and programs you created or installed.
If Windows is not responding, but the computer is working, follow these steps to perform a System
Recovery.
1. Turn off the computer. If necessary, press and hold the power button until the computer turns off.
2. Disconnect all peripheral devices from the computer, except the monitor, keyboard, and mouse.
3. Press the power button to turn on the computer.
4. As soon as you see the HP logo screen, repeatedly press the F11 key on your keyboard until the
Windows is Loading Files… message appears on the screen.
5. At the HP Recovery Manager screen, follow the on-screen instructions to continue.
6. When Windows has loaded, shut down the computer, reconnect all peripheral devices, and then
turn the computer back on.
System Recovery using recovery media (select models only)
Use the steps provided in this section if you created recovery media using Creating recovery media
using HP Recovery Manager (select models only) on page 213. If you used HP Recovery Disc Creator
to create a Windows 7 operating system DVD and a Driver Recovery DVD, use the steps in
Using HP
Recovery Disc operating system discs (select models only) on page 218.
CAUTION: System Recovery deletes all data and programs you have created or installed. Back up
any important data to a CD or DVD or to a USB flash drive.
Backing up, restoring, and recovering in Windows 7
217

Table of Contents

Other manuals for HP ProDesk 490 G1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProDesk 490 G1 and is the answer not in the manual?

HP ProDesk 490 G1 Specifications

General IconGeneral
Tcase72.72 °C
Bus typeDMI2
SteppingC0
Processor cache8 MB
Processor cores4
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-4700 Desktop series
Processor socketLGA 1150 (Socket H3)
Processor threads8
Processor codenameHaswell
Processor frequency3.4 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.9 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)84 W
Number of processors installed1
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory voltage supported by processor1.5 V
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Memory slots4x DIMM
Internal memory16 GB
Memory channelsDual-channel
Memory clock speed1600 MHz
Maximum internal memory- GB
HDD size3.5 \
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Card reader integratedYes
Total storage capacity1000 GB
Intel segment taggingEnterprise, Small Business
Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
On-board graphics card ID0x412
Discrete graphics card modelNVIDIA® GeForce® GT 630
On-board graphics card modelIntel® HD Graphics 4600
Discrete graphics card memory2048 GB
Discrete graphics memory typeGDDR3
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory2 GB
On-board graphics card OpenGL version4.3
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version11.2/12
On-board graphics card dynamic frequency (max)1200 MHz
Number of displays supported (on-board graphics)3
Bundled softwareHP Client Security\\r HP Trust Circles Standard\\r HP Wireless HotSpot\\r HP PageLift\\r HP Recovery Manager\\r HP Support Assistant\\r HP ePrint\\r CyberLink PowerDVD\\r CyberLink Power2Go\\r Buy Office
Recovery operating systemWindows 8.1 Pro
Operating system installedWindows 7 Professional
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
HDMI ports quantity0
PS/2 ports quantity2
USB 2.0 ports quantity6
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Audio systemRealtek ALC221
Product typePC
Motherboard chipsetIntel® H87
Scalability1S
Processor codeSR149
Processor ARK ID75122
Intel TSX-NI version0.00
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal solution specificationPCG 2013D
Intel Identity Protection Technology version1.00
Power supply300 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth402 mm
Width182.8 mm
Height357 mm
Weight7140 g
