Front panel components
Drive conguration may vary by model. Some models have a bezel blank covering the slim optical drive bay.
Front panel components
(1) Slim optical drive (select products only) (6) USB port with HP Sleep and Charge*
(2) Memory card reader (select products only) (7) Audio-out (headphone)/Audio-in (microphone)
combo jackAudio-out (headphone)/Audio-in (microphone)
combo jack
(3) USB Type-C charging port (8) Hard drive activity light
(4) USB SuperSpeed ports (2) (9) Power button
(5) USB port
NOTE: The light on the power button is normally white when the power is on. If it is ashing red, there is a problem with the computer
and it is displaying a diagnostic code. Refer to the Maintenance and Service Guide to interpret the code.
2 Chapter 1 Product features
