7. Slide the 2.5-inch hard drive to the left as far as it will go, and then remove the 2.5-inch hard drive (3).
Follow these steps to remove a 3.5-inch hard drive:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 32).
2. Remove the access panel (see Access panel on page 33).
3. Position the computer with the rear panel toward you.
4. Disconnect the power cable (1) from the 3.5-inch hard drive.
5. Disconnect the data cable (2) from the 3.5-inch hard drive.
38 Chapter 4 Removal and replacement procedures
