Cabling 47
1. Connect the HP c-Class Blade SUV cable to the server blade.
2. Connect the video connector to a monitor.
3. Connect a USB hub to one USB connector.
4. Connect the following to the USB hub:
o USB CD/DVD-ROM drive
o USB keyboard
o USB mouse
o USB diskette drive
Item Description
1
Monitor
2
USB CD/DVD-ROM drive or diskette drive
3
USB keyboard
4
USB hub
5
USB mouse
6
HP c-Class Blade SUV Cable
