Removal and replacement procedures 74
3.
Release the power cord from the the hook-and-loop strap.
4. Remove all power:
a. Disconnect the power cord from the power source.
b. Disconnect the power cord from the server.
5. Remove the power input module from the RPS backplane.
To replace the component, reverse the removal procedure.
RPS backplane
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
CAUTION: To prevent damage to electrical components, take the appropriate anti-static
precautions before beginning any installation, removal, or replacement procedure. Improper
grounding can cause electrostatic discharge.
To remove the component:
1. Power down the server (on page 29).
