Hardware options installation 38
6. Using a T-15 Torx screwdriver, install the dedicated iLO 2 management port module.
7. Install the access panel.
8. Install the server into the rack.
Expansion board option
To install the component:
1. Power down the server (on page 16).
2. Remove the server from the rack (on page 16).
3. Remove the access panel (on page 17).
4. Disconnect all internal cables connected to any existing expansion boards.
5. Remove the PCI riser board assembly (on page 18).
6. Remove the expansion slot cover.
