Cabling 52
Embedded SATA controller cabling (optional hard drive cage
configuration)
CAUTION: When routing cables, always be sure that the cables are not in a position where
they can be pinched or air flow can be blocked.
Optional SAS controller cabling
Optional SAS controller cabling (standard configuration)
CAUTION: When routing cables, always be sure that the cables are not in a position where
they can be pinched or air flow can be blocked.
