Hardware options installation 36
o
Low-profile controller connection
9. Secure the excess length of the Mini-SAS cable in the cable clip.
10. Connect the rest of the drive cables required in this drive configuration. For more information, see
"Storage cabling (on page 54)."
11. Install the access panel (on page 19).
12. Do one of the following:
o Slide the server into the rack.
o Install the server into the rack ("Installing the server into the rack" on page 27).
13. Install the drives ("Drive options" on page 31).
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless
all bays are populated with either a component or a blank.
14. Connect each power cord to the server.
15. Connect each power cord to the power source.
