HP ProLiant DL320e - Four-Bay LFF Hot-Plug Drive Cage Cabling

Cabling 57
Four-bay LFF hot-plug drive cage cabling
• Mini-SAS cable connected to the system board
Item Description
1
Power cable
2
560-mm Mini-SAS cable
• Mini-SAS cable connected to a storage controller in the full-height expansion slot
Item Description
1
Power cable
2
Capacitor pack cable
3
890-mm Mini-SAS cable
