Component identification 14
Item Description Status
combinations (on page 14)."
2 NIC LEDs Green = Network link exists.
Flashing green = Network link and
activity exist.
Off = No link to network exists.
If power is off, the front panel LED is
not active. For status, see "Rear panel
LEDS and buttons (on page 10)."
3 AMP status Green = AMP mode enabled
Amber = Failover
Flashing amber = Invalid configuration
Off = AMP mode disabled
— All other LEDs Amber = Failure
Off = Normal
For possible failure causes, see
"Systems Insight Display LED
combinations (on page 14)."
Systems Insight Display LED combinations
When the health LED on the front panel illuminates either amber or red, the server is experiencing a
health event. Combinations of illuminated Systems Insight Display LEDs, the system power LED, and the
health LED indicate system status.
Systems Insight
Display LED and color
Health LED
System power
LED
Status
Processor (amber) Red Amber
One or more of the following conditions
may exist:
Processor in socket X has failed.
Processor X is not installed in the
socket.
Processor X is unsupported.
ROM detects a failed processor during
POST
Processor (amber) Amber Green
Processor in socket X is in a pre-failure
condition.
DIMM (amber) Red Green One or more DIMMs have failed.
DIMM (amber) Amber Green DIMM in slot X is in a pre-failure condition.
Overtemperature
(amber)
Amber Green
The Health Driver has detected a
cautionary temperature level.
Overtemperature
(amber)
Red Amber
The server has detected a hardware critical
temperature level.
Interlock (amber) Red Green
The PCI riser board assembly is not seated
properly.
Fan (amber) Amber Green One fan has failed or has been removed.
